Simulation of silicon conical field effect GAA nanotransistors with stack SiO2/HfO2 dielectric of gate

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

The issues of modeling the electrophysical characteristics of a silicon conical field effect GAA nanotransistor are discussed. An analytical model of the drain current of a transistor with a fully enclosing conical gate with a stack sub-gate oxide SiO2/HfO2 has been developed, taking into account the effect of the charge of the interphase trap at the Si/SiO2 interface. To simulate the potential distribution in a conical working area under the condition of constant trap density, an analytical solution of the Poisson equation was obtained using the method of parabolic approximation in a cylindrical coordinate system with appropriate boundary conditions. The potential model was used to develop an expression for the GAA drain current of a nanotransistor with a stack gate oxide. The key electrophysical characteristics are numerically investigated depending on the density of traps and the thicknesses of SiO2 and HfO2 layers.
