Carrier Scattering Analysis in AlN/GaN HEMT Heterostructures with an Ultrathin AlN Barrier

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

Experimental AlN/GaN heterostructures (HSs) with an ultrathin AlN barrier were obtained using molecular beam epitaxy with plasma activation of nitrogen. The layer resistance of the optimized structures was less than 230 Ω/¨. The scattering processes that limit the mobility of two-dimensional electron gas in undoped AlN/GaN HSs with an ultrathin AlN barrier have been studied. It is shown that in the ns range characteristic of AlN/GaN HEMT HSs (ns > 1 × 1013 cm–2), a noticeable contribution to the scattering of charge carriers is made by the roughness of the heterointerface.
